There are many different ways you can mount your Bushman DC65-X upright fridge, this includes: using the supplied mounting frame, purchasing a Bushman aluminium fridge box, using the internal mounting sleeves or even creating your own brackets.
The Bushman DC65-X is an efficient and reliable upright 12V fridge.
This is a popular model for boats, camper trailers and smaller caravans.
A long and skinny freezer provides extra room to stand up large bottles. The shelves are height adjustable and the door balconies have rails to prevent your items moving when you’re underway.
Install the DC65X using the free mounting kit or mount flush to your cabinetwork. If you have any questions, please contact the team at Bushman anytime.
Independent Awards Winner
Best 12V Caravan Fridge 2020 + 2021 + 2022 productreview.com.au
- 5 Year compressor warranty
- Genuine Bushman designed cooling system
- Secop Danfoss BD35 compressor
- Compressor is German designed / Japanese owned
- Designed for off-road use
Light on Power
- Extra low-power design for superior performance
- Extensive ventilation options
- Variable speed drive compressor (2A – 4.5A)
- Average 1.0 Amp/hr over 24hrs (25º ambient, 4º fridge)
Easy to Use
- Easy to use thermostat
- Large door shelves
- Room to stand up tall bottles
- Anderson plug connection
Small, light and big on storage
Get heaps of storage space for the overall size and weight of your fridge
Super strong, yet simple design
Get fast cool-down and use less power with Bushman’s efficient and reliable cooling system. Plus, upgraded HD wire shelves to handle all the bumps
It’s the little things that make a Bushman fridge great. Like our super-soft custom made rubber feet that give your fridge a smooth ride
360° Product View
Temperature fridge4º ( +/- 2ºC)
Temperature freezer-12º ( +/- 2ºC)
DimensionsHeight 525mm, Width 450mm, Depth 515mm
Minimum cut out (flush mount)Height 530mm, Width 455mm, Depth 515mm (Allows a 50mm gap at rear when installed with the door sitting proud from the cabinetwork)
How do I mount my Bushman DC65-X fridge?
Does the door on the Bushman DC65-X protrude past the outside of the fridge cabinet when it is opened at 90˚?
No, the door on the Bushman DC65-X does not protrude past the fridge cabinet when opened 90˚, however the door handle does (20mm).
How tall is the Bushman DC65-X door?
The door on the Bushman DC65-X is 520mm tall including the handle. If you move the handle to the side of the door, the door height without the handle is only 505mm
Can I fit 2L milk bottles in the Bushman DC65-X door?
No, 2L milk bottles do not fit in the door of the Bushman DC65-X. You can fit 1L milk bottles.
What are the dimensions of the wire shelves in the Bushman DC65-X?
The wire shelves in the Bushman DC65-X are approximately 370mm wide and 330mm deep.
What are the freezer dimensions for the Bushman DC65-X?
The freezer dimensions in the Bushman DC65-X are approximately 210mm wide, 220mm deep and 90mm tall. Please note the freezer has rounded corners.
What size battery do I need for the Bushman DC65-X?
We recommend a 120Ah deep cycle (AGM) or 75Ah lithium. This will run the Bushman DC65-X for at least three days and nights.
How many watts of solar do I need for the Bushman DC65-X?
To run the Bushman DC65-X you will need approximately 200W of solar paired with a 120Ah AGM or 75Ah lithium battery.
Can the door on the Bushman DC65-X open from the other side?
Yes! With the Bushman DC65-X you can move the hinges from the right side to the left side. The door handles can also be moved to accommodate this.
What colour is the Bushman DC65-X available in?
The Bushman DC65-X is only available in matte black.
Can I run the Bushman DC65-X from 240V power?
Yes, you could operate the Bushman DC65-X on 240V power by using a 240V to 12V transformer, however most customers choose to run their fridge from their battery bank all the time. When they have access to 240V power they plug in their smart battery charger to maintain their battery bank.
